Mechanics

M-W1 : Standing Waves (I)

Unit

Waves

Purpose

Show transverse standing waves

Equipment

  1. Six-feet coil-spring
  2. Small clamp

Suggestions

Demonstrate

  1. Traveling pulse, reflected pulse
  2. Speed of a pulse as a function of tension
  3. Standing waves (two fixed ends) (one to five antinodes can be reliably produced)

Discussion

  1. 2 nodes, 1 antinode
  2. 3 nodes, 2 antinodes
  3. 4 nodes, 3 antinodes
  4. 5 nodes, 4 antinodes
  5.  nodes, antinodes
  6.  nodes, antinodes

M-W2 : Standing Waves (II)

Unit

Waves

Purpose

Demonstrate standing waves, the effect of tension in a string on wave speed, the role of frequency

Equipment

  1. Cenco wave demonstrator
  2. Clamp or knob
  3. Hand drill with variable speed

Suggestions

  1. At a fixed rate of rotation, vary the tension
  2. Change the speed, adjust the tension to the nearest standing wave; repeat.

Discussion

See attached

M-W3 : Pulse on String

Unit

Transverse Waves

Purpose

Compare waves speed for two different strings

Equipment

  1. Two strings of different mass density
  2. Clamp to secure one end of strings

Suggestions

Set the strings in parallel and ask students to predict on which will a pulse travel faster if

  1. Strings loose
  2. Strings taut with the same tension

Discussion

M-W4 : Travelling Wave

Unit

Waves

Purpose

Illustrates the nature of a transverse wave and rolling water wave

Equipment

  1. Plexi-glass water tank
  2. Cranberry juice or dye
  3. Red marker ball
  4. Wooden block to create a wave
  5. White paper marker arrow to indicate the position of the ball

Suggestions

Discussion

  1. Set-up
  2. Block to be plunged into tank to initiate a wave
  3. A wave pulse is sent
  4. A wave crest passes by the ball, but does not move the ball horizontally
  5. A wave crest reaches the edge of the tank; the marker ball is still oriented with the paper arrow

M-W5 : Small Ripple Tank

Unit

Water Waves

Purpose

Illustrate circular and planar waves, interference, reflection

Equipment

  1. Ripple tank
  2. Wave generator
  3. Accessories: probs, barriers, wetting agent (soap)
  4. Stand with a clamp
  5. Variable low-voltage power supply (0-6V, 0-1A)
  6. Overhead projector

Suggestions

See the attached instructions

Discussions

See attached

  1. Set-up
  2. Pouring in the water colored with cranberry juice
  3. Close-up of the hand-held wave generator
  4. One Huygens source
  5. Two Huygens sources
  6. Hand-held wave generator with attachment for a planar wave
  7. Planar wave

M-W6 : Large Ripple Tank

Unit

Waves

Purpose

Demonstrate: Huygens Principle, Young's Experiment interference pattern, focus by a concave "water mirror", etc.

Equipment

  1. PASCO Ripple tank apparatus (square tank on four legs, wave generator, halogen light source
  2. Assorted implements such as barriers, plungers, flat edge, etc.
  3. A white cardboard screen OR
  4. PASCO translucent screen attachent
  5. A pitcher with water

Suggestions

To obtain regular wave patterns it is necessary to keep the vibrating elements clean of grease so that
they are properly wetted by the water. The water depth for interference experiments should be about
1cm (deeper for refraction experiments). Best results with an amplitude setting of 2-4. Explore the role
of phase difference and frequency.

Discussion

Regarding the concave water mirror (Pic. 12 below), the focus point at half a radius is manifested
as a "Huygens source."

1. Set-up
2-6. Two Huygens sources with increasing separation
7. Planar wave with a disturbance to be avoided
8. Correctly formed planar wave
9. Huygens source created by a planar wave impacting a 1.5cm slit
10-11. Two Huygens sources created by two 1.5cm slits and the interference pattern
12. A planar wave collides with a concave plate causing the incoming waves to reflect and converge at a focal point

M-W7 : Organ Pipe

Unit

Longitudinal Waves

Purpose

Demonstrate standing waves in an open-end and closed-end organ pipe

Equipment

  1. Large wooden organ pipe [NYA]
  2. Stopper with a seal

Suggestions

Blow the pipe without and with stopper, compare the pitch

Discussion

M-W8 : Acoustic Doppler

Unit

Doppler Effect

Purpose

Simple demonstration of the Doppler Effect in sound waves

Equipment

  1. Tuning fork, and a mallet
  2. A string

Suggestions

Strike the tuning fork and whirl it above head on a string varying speed and direction

Discussion

MW8-Acoustic-Doppler-(1)-sm-

M-W9 : Dopler Rocket

Unit

Doppler Effect

Purpose

High speed demonstration of the Doppler Effect in sound waves

Equipment

  1. Pasco Dopler Rocket
  2. String with handles

Suggestions

  1. Stretch the strings along the aisles of the lecture hall (don't clip anyone's head)
  2. Pull before the rocket hits your handles so that the rocket is continuously moving.

Discussion

  1. Dopler Rocket
  2. Rocket moving Down
  3. Rocket moving Up

M-W10 : Singing Rod

Unit

Sound Waves

Purpose

To dramatically illustrate standing waves in a solid

Equipment

  1. Crushed Rosin
  2. Singing Rods (61, 76, 91 cm)

Suggestions

  1. Firmly hod the rod vertically at the midpoint
  2. Gently stroke the rod from the center to the end using your rosin covered thumb and forfinger
  3. Try holding the rod at other predicted nodes.

Discussion

  1. Equipment
  2. Singing rod in use
